TYPE XL-90

GEAR RATIO

INPUT RPM

OUTPUT RPM

INP. HP

INP. KW

OUT.TORQ.Nm GEAR SPECIFICATION WEIGHT LUBRICATING OIL

1: 4.11

540 / 1000

2219 / 4110

61 / 94

45 / 69

193 / 161



Kg 42

TYPE QUANTITY 1

1: 3.10

540 / 1000

1674 / 3100

73 / 112

54 / 82

306 / 254



Kg 42

SAE.90EP

1: 2.58

540 / 1000

1393 / 2580

82/ 125

60 / 92

414 / 340



Kg 42

1: 1.93

540 / 1000

1042 / 1930

82 / 125

60 / 92

553 / 455



Kg 42

1.93: 1

540 / 1000

280 / 518

50 / 77

37 / 57

1256 / 1044



Kg 42

2.58: 1

540 / 1000

209 / 388

44 / 68

32 / 50

1477 / 1233



Kg 42

3.10: 1

540 / 1000

174 / 323

33 / 51

24 / 37

1331 / 1111



Kg 42

4.11: 1

540 / 1000

131 / 243

25 / 38

18 / 28

1337 / 1097



Kg 42



TYPE XL-101


GEAR RATIO

INPUT RPM

OUTPUT RPM

INP. HP

INP. KW

OUT.TORQ.Nm GEAR SPECIFICATION WEIGHT LUBRICATING OIL

1: 4.11

540 / 1000

2219 / 4110

90 / 138

66 / 101

285 / 236



Kg 48

TYPE QUANTITY 1

1: 3.10

540 / 1000

1674 / 3100

120 / 185

88 / 136

504 / 419



Kg 48

1: 2.46

540 / 1000

1328 / 2460

120 / 185

88 / 136

635 / 528



Kg 48

1: 1.93

540 / 1000

1042 / 1930

145 / 220

107 / 162

978 / 801



Kg 48

1.93: 1

540 / 1000

280 / 518

90 / 135

66 / 99

2260 / 1831



Kg 48

2.46: 1

540 / 1000

220 / 407

63 / 95

46 / 70

2016 / 1642



Kg 48

3.10: 1

540 / 1000

174 / 323

55 / 85

40 / 62

2218 / 1851



Kg 48

4.11: 1

540 / 1000

131 / 243

37 / 55

27 / 40

1979 / 1588



Kg 48
